Quality
|
Leyer Height |
0,2 mm |
|
Initial Layer Height |
0,2 mm |
|
Line Width |
0,4 mm |
|
Initial Layer Line Width |
150 % |
Shell
|
Wall Thickness |
1,2 mm |
|
Wall Line Count |
3 |
|
Top Surface Skin Layers |
3 |
|
Top Bottom Thickness |
1,2 mm |
|
Optimize Wall Printing Order |
On |
|
Compensate Wall Overlaps |
On |
Infill
|
Infill Density |
25 % |
|
Infill Pattern |
Grid |
|
Connect Infill Lines |
On |
|
Infill Overlap Percentage |
20 % |
Material
|
Printing Temperatur |
195 Grad C |
|
Printing Temperatur Initial Layer |
200 Grad C |
|
Build Plate Temperatur |
60 Grad C |
|
Flow |
100 % |
|
Initial Layer Flow |
150 % |
|
Enable Retraction |
On |
|
Retract at Layer Change |
On |
|
Retraction Distance |
6 mm |
|
Retraction Speed |
60 mm/s |
|
Retraction Minimum Travel |
1,5 mm |
Speed
|
Print Speed |
60 mm/s |
|
Infill Speed |
60 mm/s |
|
Wall Speed |
30 mm/s |
|
Outer Wall Speed |
30 mm/s |
|
Inner Wall Speed |
60 mm/s |
|
Top Surface Skinn Speed |
30 mm/s |
|
Top/Bottom Speed |
60 mm/s |
|
Support Speed |
60 mm/s |
|
Support Infill Speed |
60 mm/s |
|
Support Interface Speed |
40,0 mm/s |
|
Support Speed |
60 mm/s |
|
Support Infill Speed |
60 mm/s |
|
Support Interface Speed |
60 mm/s |
|
Support Roof Speed |
40,0 mm/s |
|
Support Floor Speed |
40,0 mm/s |
|
Travel Speed |
100 mm/s |
|
Initial Layer Speed |
25 mm/s |
|
Initial Layer Print Speed |
25 mm/s |
|
Initial Layer Travel Speed |
50 mm/s |
|
Skirt/Brim Speed |
25 mm/s |
|
Maximum Z Speed |
0 mm/s |
|
Number of Slower Layers |
2 |
|
Equalize Filament Flow |
Off |
|
Enable Acceleration Control |
On |
|
Print Acceleration |
1800 mm/s |
|
Infill Acceleration |
1800 mm/s |
|
Wall Acceleration |
1800 mm/s |
|
Outer Wall Acceleration |
1800 mm/s |
|
Inner Wall Acceleration |
1800 mm/s |
|
Top Surface Skinn Acceleration |
1800 mm/s |
|
Top/Bottom Acceleration |
1800 mm/s |
|
Support Acceleration |
1800 mm/s |
|
Support Infill Acceleration |
1800 mm/s |
|
Support Interface Acceleration |
1800 mm/s |
|
Support Roof Acceleration |
1800 mm/s |
|
Support Floor Acceleration |
1800 mm/s |
|
Travel Acceleration |
3000 mm/s |
|
Initial Layer Acceleration |
1800 mm/s |
|
Initial Layer Print Acceleration |
1800 mm/s |
|
Initial Layer Travel Acceleration |
3000 mm/s |
|
Skirt/Brim Acceleration |
1800 mm/s |
|
Enable Jerk Control |
On |
|
Print Jerk |
5 mm/s |
|
Infill Jerk |
5 mm/s |
|
Wall Jerk |
5 mm/s |
|
Outer Wall Jerk |
5 mm/s |
|
Inner Wall Jerk |
5 mm/s |
|
Top Surface Skin Jerk |
5 mm/s |
|
Top/Bottom Jerk |
5 mm/s |
|
Support Jerk |
5 mm/s |
|
Support Infill Jerk |
5 mm/s |
|
Support Interface Jerk |
5 mm/s |
|
Support Roof Jerk |
5 mm/s |
|
Support Floor Jerk |
5 mm/s |
|
Travel Jerk |
10 mm/s |
|
Initial Layer Jerk |
5 mm/s |
|
Initial Layer Print Jerk |
5 mm/s |
|
Initial Layer Travel Jerk |
10,0 mm/s |
|
Skirt/Brim Jerk |
5 mm/s |
Travel
|
Combing Mode |
Off |
|
Z Hop When Retracted |
On |
Cooling
|
Enable Print Cooling |
On |
|
Fan Speed |
100 % |
|
Regular Fan Speed |
100 % |
|
Initial Fan Speed |
0 % |
|
Regular Fan Speed at Height |
0,4 mm |
|
Minimum Layer Time |
5 |
Support
|
Generate Support |
On |
|
Support Placement |
Everywhere |
|
Support Overhang Angle |
50 |
|
Support Pattern |
Zig Zag |
|
Support Wall Line Count |
0 |
|
Connect Support ZigZags |
On |
|
Support Density |
20 % |
|
Support Line Distance |
1,25 mm |
|
Support Z Distance |
0,2 mm |
|
Support Top Distance |
0,2 mm |
|
Support Bottom Distance |
0,2 mm |
|
Support X/Y Distance |
0,7 mm |
|
Support Distance Priority |
Z overrides X/Y |
|
Minimum Support X/Y Distance |
0,125 mm |
|
Support Stair Step Height |
0,3 mm |
|
Support Stair Step Minimum Width |
5,0 mm |
|
Support Join Distance |
2,0 mm |
|
Support Horizontal Expansion |
0,2 mm |
|
Support Infill Layer Thickness |
0,2 mm |
|
Gradual Support Infill Steps |
0 |
|
Enable Support Interface |
On |
|
Enable Support Roof |
On |
|
Enable Support Floor |
On |
|
Support Interface Thickness |
1 mm |
|
Support Roof Thickness |
1 mm |
|
Support Floor Thickness |
1 mm |
|
Support Interface Resolution |
0,3 mm |
|
Support Interface Density |
50 % |
|
Support Roof Density |
50 % |
|
Support Roo..ne Distance |
0,5 mm |
|
Support Floor Distance |
50 % |
|
Support Flo..ne Distance |
0,5 mm |
|
Support Interface Pattern |
Zig Zag |
|
Support Roof Pattern |
Zig Zag |
|
Support Floor Pattern |
Zig Zag |
|
Use Towers |
Off |
Build Plate Adhesion
|
Build Plate Adhesion Type |
Skirt |
|
Skirt Line Count |
3 |
|
Skirt Distance |
8 mm |
Mesh Fixes
|
Union Overlapping Volumes |
Off |
|
Remove All Holes |
Off |
Experimental
|
Tree Support |
Off |
|
Enable Coasting |
On |
|
Coasting Volume |
0,1 mm |
